Sprinte ASP116 Evolution
TECHNOLOGY
SD card for
- Storing information
- Updating programs
- Operating history
- Storing diagrams and technical specifications (record drawings)
MP3 speech synthesis built in
CAN OPEN LIFT BUS communication for card management on the landings and in the car
Absolute encoder on the car roof millimetre stopping accuracy (optional)
SPECIFICATION
- Single trailing cable
- Speech synthesis in car and landings EN81 70
- Hydraulic traction, traction VVF & MRL
- Fault logon SD card, Excel compatible
- Speed up to 1.6m/s (3m/s under trails now)
- Electric call control
- Choice of optical reader or absolute encoder
- 32 floors
- Control : APB, up/down, full collective and multiplexing 4 lifts
- Electrical backstop NF 82-
212
- For landings choice of CAN OPEN LIFT BUS or conventional cabling
- Temperature regulation and control management
- Site control for provisional movement
